As with the entire MV lineup, MV12 features an innovative architecture which places high-endurance storage locally on the camera and removes the network video recorder (NVR) from the equation. Not only does this drastically simplify both installation and scaling, but it also eliminates a major network security vulnerability in the IT infrastructure.
Features like LLDP insights, offline device alerting, and built-in remote troubleshooting tools reduce time to resolution and free up personnel to make IT improvements, providing added business value. And, because MV is managed through the browser-based Meraki dashboard and operates using a licensing model, there's no need to purchase, download, and maintain any additional software. Management through the Meraki dashboard ensures firmware updates will continually roll out over the lifespan of the product, meaning its value will only increase over time.
| Camera |
| Camera |
1/3" 4MP (2688x1520) progressive CMOS image sensor, 128GB high endurance solid state storage (MV12WE), 256GB high endurance solid state storage (MV12N and MV12W), 2.8mm focal length fixed lens (MV12W and MV12WE), 3.8mm focal length fixed lens (MV12N), f/1.8 aperture, Field of view<ul><li>Horizontal 114° (MV12W and MV12WE)<li>Horizontal 73° (MV12N)<li>Vertical 61° (MV12W and MV12WE)<li>Vertical 44° (MV12N)<li>Diagonal 132° (MV12W and MV12WE)<li>Diagonal 86° (MV12N)</ul> 1/30s to 1/32,000s shutter speed, Minimum illumination 0.18 Lux (standard recording) and 0.01 Lux (night mode), Built-in IR illuminators, effective up to 15m (49ft) |
| Data Security |
| Data Security |
Full disk encryption (AES 256-bit), Automatically purchased and provisioned TLS certificates (publicly-signed), Management encryption and two-factor authentication |
| Environment |
| Environment |
Starting temperature 0°C - 40°C (32°F - 104°F), Working temperature 0°C - 40°C (32°F - 104°F) |
| Features |
| Features |
Cloud managed with complete integration into the Meraki dashboard, Plug and play deployment with self-configuration, Dynamic day-to-night transition with IR illumination, Noise optimized motion indexing engine with historical search, Shared video wall with individual layouts supporting multiple cameras, Selective export capability with cloud proxy (with watermarked timestamps), Highly granular view, review, and export user permissions with SAML integration, Motion heat maps for relative hourly or day-by-day motion overview, Motion alerts |
| In the box |
| In The Box |
Quick start & installation guide, MV camera hardware, Wall mounting kit |
| Networking |
| Networking |
1x 10/100/1000 Base-T Ethernet (RJ45), Dual band WLAN with antenna diversity supporting 2.4GHz and 5GHz, 802.11 a/b/g/n/ac, DSCP traffic marking |
| Physical characteristics |
| Physical Characteristics |
Dimensions 106mm x 74mm (diameter x height), Fixed lens, Weight 286g, Female RJ45 Ethernet connector, Multicolor, multifunction status LED, Reset button |
| Specs 6 |
| Specs 6 |
Power:Power consumption 12.95W maximum via 802.3af PoE |
| Video |
| Video |
1080p HD video recording (1920x1080) with H.264 encoding, up to 20fps, Cloud augmented edge storage (locally stored video with metadata in the cloud), Optimized retention settings (scheduling and motion-based) for variable retention, Up to 40 days of video storage per camera, Direct live streaming with no client software (native browser playback), Stream video anywhere with automatic cloud proxy, High dynamic range (HDR) |
| Warranty |
| Warranty |
Warranty 3 year hardware warranty with advanced replacement |
