The CyberPower BP192VL2U01 is a high-capacity external battery module designed to extend the runtime of compatible UPS systems, ensuring sustained power supply during outages and critical operations. This 2U rackmount unit is equipped with a robust 192V DC battery array, ideal for businesses seeking to enhance the endurance of their power backup solutions. Featuring a durable steel enclosure, the BP192VL2U01 seamlessly integrates with existing setups, providing a reliable energy reserve for data centers, industrial applications, and other mission-critical environments.
The BP192VL2U01 offers easy connectivity and management options, designed to work in tandem with CyberPower's OL series UPS systems. Advanced battery management technology optimizes charging and discharging cycles to extend battery life, while the hot-swappable design ensures maintenance can be performed without interrupting power to connected equipment. This battery module is supported by a 3-year limited warranty, offering assurance of quality and reliability, while its seamless compatibility with PowerPanel Business Edition software facilitates comprehensive monitoring and management of your backup power infrastructure.
| Battery Features |
| Battery Quantity |
16 |
| Battery Size |
12V / 5.7 Ah |
| Battery Type |
Sealed Lead-Acid Battery |
| Hot Swappable |
Yes |
| Recharge Time |
4 Hours (0% to 90% charged) |
| Compliance & Warranty |
| RoHS Compliant |
RoHS Compliant |
| Safety |
UL1778 CSA C22.2 No.107.3 FCC Part 15 Class A |
| Warranty |
3 Year Limited Warranty |
| Physical Properties |
| Actual Dimensions (in) |
17.05 x 3.4 x 28.3 (in) |
| Actual Weight (lb) |
101.4 |
| Rack Mounting Hardware Included |
Yes |
| Shipping Dimensions (in) |
23.54 x 8.39 x 43.23 (in) |
| Shipping Weight (lb) |
119.3 |
| Runtime and Battery Maintenance |
| Battery Replaceability |
No |
| Unit Configuration |
| Form Factor |
Rack / Tower |
| Model ID |
BP192VL2U01 |
| Rack Unit Size |
2U |
