FortiWiFi 30E Hardware Appliance Appliances

FortiWiFi 30E Hardware Appliance

Availability:Out Of Stock

Available Options

The FortiGate/FortiWiFi 30E are compact, cost effective, all-in-one security appliances that deliver Fortinet's Connected UTM. Ideal for small business, remote, customer premise equipment (CPE) and retail networks, these appliances offer the network security, connectivity and performance you need.
Download PDF datasheet for detailed product information Download PDF datasheet for included services
Regulatory Compliance FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB
Form Factor Desktop
Height X Width X Length (inches) 1.61 x 8.27 x 5.24
Height X Width X Length (mm) 41 x 210 x 133
Weight 1.982 lbs (0.899 kg) 2.008 lbs (0.911 kg)
Heat Dissipation 52 BTU/h
Humidity 20-90% non-condensing
Maximum Current 100V / 0.6A, 240V / 0.4A
Operating Altitude Up to 7,400 ft (2,250 m)
Operating Temperature 32-104°F (0-40°C)
Power Consumption (Average / Maximum) 13 / 15 W
Power Required 100-240V AC, 60-50 Hz(External DC Power Adapter)
Storage Temperature -31-158°F (-35-70°C)
Hardware Specifications
Console (RJ45) 1
GE RJ45 Switch Ports 4
GE RJ45 WAN Port 1
Internal Storage 16 GB
USB Port 1
System Performance
CAPWAP Throughput 950 Mbps
Client-to-Gateway IPsec VPN Tunnels 250
Concurrent Sessions (TCP) 900,000
Concurrent SSL-VPN Users (Recommended Maximum) 80
Firewall Policies 5,000
Firewall Throughput 950 Mbps
Firewall Throughput (Packets Per Second) 180 Kpps
Gateway-to-Gateway IPsec VPN Tunnels 20
High Availability Configurations Active/Active, Active/Passive, Clustering
IPS Throughput (HTTP / Enterprise Mix) 600 / 240 Mbps
IPsec VPN Throughput (512 Byte Packets) 75 Mbps
Maximum Number Of FortiAPs (Total / Tunnel Mode) 2 / 2
Maximum Number Of FortiTokens 20
Maximum Number Of Registered FortiClients 200
New Sessions/Second (TCP) 15,000
NGFW Throughput 150 Mbps
SSL Inspection Throughput 200 Mbps
SSL-VPN Throughput 35 Mbps
Virtual Domains (Default / Maximum) 5 / 5
