The Fortinet Enterprise Firewall Solution delivers end-to-end network security with one platform, one network security operating system and unified policy management with a single pane of glass - for the industry's best protection against the most advanced security threats and targeted attacks.
Download PDF datasheet for detailed product information
Download PDF datasheet for included services
| Compliance |
| Safety |
FCC Part 15B, Class B, CE, RCM, VCCI, UL/cUL, CB, BSMI |
| Dimensions |
| Form Factor |
Desktop |
| Height X Width X Length (inches) |
1.65 x 8.5 x 7 |
| Height X Width X Length (mm) |
42 x 216 x 178 |
| Weight |
2.65 lbs (1.2 kg) |
| Environment |
| Heat Dissipation |
467.5 BTU/h |
| Humidity |
20-90% non-condensing |
| Maximum Current |
115V AC / 1.2A, 230V AC / 0.6A |
| Operating Altitude |
Up to 16,404 ft (5,000 m) |
| Operating Temperature |
32-104°F (0-40°C) |
| Power Consumption (Average / Maximum) |
20 / 137 W |
| Power Required |
100-240V AC, 50-60 Hz |
| Storage Temperature |
-31-158°F (-35-70°C) |
| Hardware Specifications |
| Console (RJ45) |
1 |
| GE RJ45 DMZ/HA Ports |
2 |
| GE RJ45 PoE/+ Ports |
12 |
| GE RJ45/SFP Shared Media Pairs |
2 |
| Internal Storage |
- |
| USB Ports |
1 |
| System Performance |
| Application Control Throughput |
800 Mbps |
| CAPWAP Throughput |
2.2 Gbps |
| Client-to-Gateway IPsec VPN Tunnels |
1,000 |
| Concurrent Sessions (TCP) |
1.3 Million |
| Concurrent SSL-VPN Users (Recommended Maximum) |
200 |
| Firewall Policies |
5,000 |
| Firewall Throughput (1518 / 512 / 64 Byte UDP Packets) |
4 / 4 / 4 Gbps |
| Firewall Throughput (Packets Per Second) |
6 Mpps |
| Gateway-to-Gateway IPsec VPN Tunnels |
200 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| IPS Throughput (HTTP / Enterprise Mix) |
1.5 Gbps / 450 Mbps |
| IPsec VPN Throughput (512 Byte Packets) |
2.5 Gbps |
| Maximum Number Of FortiAPs (Total / Tunnel Mode) |
32 / 16 |
| Maximum Number Of FortiTokens |
100 |
| Maximum Number Of Registered FortiClients |
200 |
| New Sessions/Second (TCP) |
30,000 |
| NGFW Throughput |
360 Mbps |
| SSL Inspection Throughput |
350 Mbps |
| SSL-VPN Throughput |
200 Mbps |
| Threat Protection Throughput |
250 Mbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
