The Fortinet Enterprise Firewall Solution delivers end-to-end network security with one platform, one network security operating system and unified policy management with a single pane of glass - for the industry's best protection against the most advanced security threats and targeted attacks.
Download PDF datasheet for detailed product information
Download PDF datasheet for included services
| Certifications |
| ICSA Labs |
Firewall, IPsec, IPS, Antivirus, SSL-VPN; IPv6 |
| Compliance |
| Safety |
FCC Part 15B, Class A, CE, RCM, VCCI, UL/cUL, CB, BSMI |
| Dimensions |
| Form Factor |
Rack Mount, 1 RU |
| Height X Width X Length (inches) |
1.7 x 17.0 x 11.9 |
| Height X Width X Length (mm) |
44 x 432 x 301 |
| Weight |
12.12 lbs (5.5 kg) |
| Environment |
| Heat Dissipation |
374.9 BTU/h |
| Humidity |
10-90% non-condensing |
| Maximum Current |
110 V / 7 A, 220 V / 3.5 A |
| Operating Altitude |
Up to 7,400 ft (2,250 m) |
| Operating Temperature |
32-104°F (0-40°C) |
| Power Consumption (Average / Maximum) |
70.98 / 109.9 W |
| Power Required |
100-240V AC, 60-50 Hz |
| Storage Temperature |
-31-158°F (-35-70°C) |
| Hardware Specifications |
| Console (RJ45) |
1 |
| GE RJ45 Management/HA Ports |
2 |
| GE RJ45 Ports |
14 |
| GE RJ45 WAN Interfaces |
2 |
| GE SFP Slots |
4 |
| Local Storage |
480 GB |
| USB (Client / Server) |
1 / 1 |
| System Performance |
| Client-to-Gateway IPsec VPN Tunnels |
5,000 |
| Concurrent Sessions (TCP) |
2 Million |
| Concurrent SSL-VPN Users (Recommended Maximum) |
300 |
| Firewall Policies |
10,000 |
| Firewall Throughput (1518 / 512 / 64 Byte UDP Packets) |
20 / 20 / 9 Gbps |
| Firewall Throughput (Packets Per Second) |
13.5 Mpps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2,000 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| IPsec VPN Throughput (512 Byte Packets) |
9 Gbps |
| Maximum Number Of FortiAPs (Total / Tunnel Mode) |
128 / 64 |
| Maximum Number Of FortiTokens |
1,000 |
| Maximum Number Of Registered FortiClients |
600 |
| New Sessions/Second (TCP) |
135,000 |
| SSL-VPN Throughput |
900 Mbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
