With network bandwidth requirements doubling every 18 months and increases in sophisticated cyber threats, enterprise organizations with large branch offices know they need high-speed network security that also delivers highly effective next generation security.
Download PDF datasheet for detailed product information
Download PDF datasheet for included services
| Dimensions and power |
| AC Power Supply |
100-240V AC, 60-50 Hz, 300 W Redundant |
| Current (Maximum) |
100V/5A, 240V/3A |
| Form Factor |
1 RU |
| Heat Dissipation |
638.75 BTU/h |
| Height X Width X Length (inches) |
1.74 x 17.22 x 18.24 |
| Height X Width X Length (mm) |
44.2 x 437.5 x 463.2 |
| Power Consumption (Average / Maximum) |
135 W / 187.2 W |
| Redundant Power Supplies |
Yes |
| Weight |
20.24 lbs (9.18 kg) |
| Interfaces and modules |
| Console Port |
1 |
| GE RJ45 Management / HA Ports |
2 |
| Hardware Accelerated 10 GE SFP+ Slots |
2 |
| Hardware Accelerated GE RJ45 Ports |
16 |
| Hardware Accelerated GE SFP Slots |
16 |
| Onboard Storage |
256 GB |
| USB Ports (Client / Server) |
1 / 2 |
| Operating environment and certifications |
| Certifications |
ICSA Labs |
| Compliance |
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
| Humidity |
20-90% non-condensing |
| Operating Altitude |
Up to 7,400 ft (2,250 m) |
| Operating Temperature |
32-104°F (0-40°C) |
| Storage Temperature |
-31-158°F (-35-70°C) |
| System performance and capacity |
| Antivirus Throughput |
3.5 Gbps |
| CAPWAP Clear-text Throughput (HTTP) |
8 Gbps |
| Client-to-Gateway IPsec VPN Tunnels |
10,000 |
| Concurrent Sessions (TCP) |
11 Million |
| Concurrent SSL-VPN Users (Recommended Maximum) |
10,000 |
| Firewall Policies |
100,000 |
| Firewall Throughput (Packet Per Second) |
49.5 Mpps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2,000 |
| High Availability Configurations |
Active-Active, Active-Passive, Clustering |
| IPS Throughput |
8 Gbps |
| IPsec VPN Throughput (512 Byte) |
25 Gbps |
| IPv4 Firewall Throughput (1518 / 512 / 64 Byte, UDP) |
52 / 52 / 33 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 86 Byte, UDP) |
52 / 52 / 33 Gbps |
| Maximum Number Of FortiAPs (Total / Tunnel) |
1024 / 512 |
| Maximum Number Of FortiTokens |
1,000 |
| Maximum Number Of Registered Endpoints |
2,000 |
| New Sessions/Second (TCP) |
280,000 |
| SSL-VPN Throughput |
3.6 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
