The CyberPower CPS1500AVR is a reliable 1500VA / 900 W line-interactive UPS designed to safeguard home and office electronics from power interruptions and voltage fluctuations. This UPS model features a compact tower form factor with eight NEMA 5-15R outlets and a six-foot NEMA 5-15P input cord. The unit offers automatic voltage regulation (AVR) to maintain a stable output voltage without resorting to battery power, thus extending battery life. It provides essential surge protection rated at 1030 joules, ensuring your equipment is shielded from electrical surges and spikes. The internal sealed lead-acid battery delivers approximately 8 minutes of runtime at half load, making it ideal for short-term backup needs during outages.
The CPS1500AVR is equipped with a multifunction LCD panel that provides real-time system vitals and status updates, ensuring easy monitoring and management. Connectivity options include USB and serial ports for integrating with management software, enhancing control over the UPS. The unit supports PowerPanel Personal Edition software, offering detailed monitoring and configuration capabilities. With a 3-year limited warranty and a $500,000 Connected Equipment Guarantee, the CPS1500AVR delivers reliable protection and peace of mind for your valuable electronic devices, ensuring they are consistently powered and safeguarded against unexpected power events.
| Battery Features |
| Battery Quantity |
4 |
| Battery Type |
Sealed Lead-Acid Battery |
| Hot Swappable |
Yes |
| Recharge Time |
8 Hours |
| Compliance & Warranty |
| CEG Amount |
$300000 |
| Safety |
UL1778 cUL FCC Part 15 Class B |
| Warranty |
3 Year Limited Warranty |
| Electrical Protection Features |
| EMI/RFI Filtration |
Yes |
| Overload Protection |
Internal Circuitry Limiting Circuit Breaker Protected |
| Surge Protection |
Yes, 1840 J |
| Input Characteristics |
| Frequency Range |
47 Hz 63 Hz |
| Plug Type |
NEMA 5-15P |
| Voltage Range |
90 VAC 140 VAC |
| Interfaces & Monitoring |
| HID Compliant USB Port |
Yes |
| Management Software |
PowerPanel Business |
| Serial Port |
1 Serial 1 Dry Contact |
| Outlet Details |
| Outlet Type |
8 NEMA 5-15R |
| Total Number of Outlets |
8 |
| Output Characteristics |
| Battery Frequency |
50/60 Hz 1% |
| Battery Voltage |
120 VAC 10% |
| Battery Waveform |
Simulated Sine Wave |
| Capacity (VA) |
1500VA |
| Capacity (Watts) |
900 W |
| Physical Properties |
| Actual Dimensions (in) |
17.25 x 3.5 x 15.75 (in) |
| Actual Weight (lb) |
50.5 |
| Color |
Black |
| Cord Length |
10 ft (3.0 m) |
| Shipping Dimensions (in) |
20.5 x 12.0 x 21.25 (in) |
| Shipping Weight (lb) |
56.50 |
| Runtime and Battery Maintenance |
| Battery Replaceability |
Yes |
| Full-Load Runtime |
7 min |
| Half-Load Runtime |
18 min |
| Unit Configuration |
| Energy Efficiency Mode |
GreenPower UPS Bypass Technology |
| Form Factor |
Rack / Tower |
| Model ID |
CPS1500AVR |
| Topology Type |
Line Interactive |
